New Products from Our Manufacturers



X-COM’s revolutionary IQC5000A records, stores, and plays back two independent 160-MHz-wide channels of signal activity captured at any frequency with high fidelity.

All in an enclosure measuring 12 x 3.5 x 10.5 inches and weighing 10 lb. that operates from commercial power in the lab or a 12 V car battery in the field.



So whether your job is ELINT, SIGINT, EW, spectrum management, or wireless or radar system testing, the IQC5000A is an indispensable companion.

2 record/playback channels - each with up to 160 MHz IBW

Long-duration spectrum capture:
- Up to 2 Tbytes internal SSD storage (22 min. to 1.7 days)
- Up to 16 Tbytes external storage (2.7 hr. to 14 days)

Exploits the lab-grade performance of signal analyzers
from Agilent, Rohde & Schwarz, or Tektronix as its RF front end

Playback at any frequency using a vector signal generator

High speed offload through PCIe



Spectro-X 4.0, X-COM’s unique signal analysis software, now provides even greater versatility for finding even the stealthiest signals of interest within spectrum capture files of any length or complexity.



What’s new in Spectro-X 4.0:
Analyze up to four recorded RF spectrum files at the same time

Display frequency, time, and magnitude plots for each channel

File alignment to plus or minus one sample

Mark event start and stop times to the sample level

Moving a marker in one domain moves all other measurements in the domain as well.












IMS Engineered Products

Racks and Internal Accessories
Ready to Ship in 24 Hours

AMCO Enclosures has just released a New 24 hour shipping program for the TN Series. Now you can get the strongest racks in the industry shipped from our factory in Des Plaines, IL. within 24 hours. These racks have a 12,250lb. Load Rating, feature a heavy duty skirted caster base with 2 ground studs, four 1000lb. levelers, two pair of 10-32 tapped mounting channels and a durable black powder coat finish.
The TN Series racks are fully welded and are available in three distinct styles:

• The PTN is a 24” wide rack and features open sides for easy access to your electronic equipment.
The PTN is available to ship in 24 hours in two heights; 37RU and 44RU and depths of 27.5’ and 32.5”.

• The BTN is a 22” wide rack and features open sides for easy access to your electronic equipment.
The BTN is available to ship in 24 hours in two heights; 37RU and 44RU and depths of 26.5”and 31.5”.

• The ETN is a 22” wide rack that includes two non-removable, vented side panels.
The ETN is available to ship in 24 hours in three heights; 35RU, 40RU and 44RU and in smaller frame depths of 20” and 25”.

Internal accessories such as; shelves, drawers and blank panels are also in stock and ready to ship within 24 hours. Other TN Series sizes are available to ship within 1-2 weeks. AMCO Enclosures Racks have a 10 year warranty and are MADE IN THE USA.



New 2 Amp Switching Matrices = 2 x Switching Density*



Pickering is proud to introduce our New
2 Amp PXI Switching Matrices


featuring:

High density 2Amp PXI Switching Matrices

  • Highest Density 3U PXI
    2A Matrices - Up to 448 crosspoints per slot

  • BRIC Matrices
    (40-56X/40-59X Series)

  • Single Slot Matrices
    (40-57X Series)

  • x4/x6/x8/x12/x16
    Analog Bus Widths

  • 1, 2, 4, and 8 PXI Module Widths

  • Over 70 Choices in Matrix Switching

To learn more about these ultra-high density switching
matrices, go here > >

* When compared to nearest PXI competitor as of April 2013







Also being introduced is Low Cost PXI Multiplexer New Low Cost PXI Multiplexer from Pickering Interfaces
The e xpansion of our PXI multiplexer range offers; low cost, high switching capacity, simple D-type connection and 18 switch configurations (nine standard and nine half density)



Click here to see all of Pickering's recent product launches...





 Comparing LXI and PXI

Presented in the  "Getting to Know LXI Video Series" from the LXI Consortium, Pickering's David Owen provides a brief overview of the PXI and LXI Standards and then compares the two technologies by discussing the advantages and disadvantages of each of them.

Video - Comparing LXI and PXI from the LXI Consortium


Take a look here > >





New Videos

ANRITSU Videos on YouTube - view

                          YOKOGAWA Videos -  view

CSZ EZT-560i Training Video

The Video Link Provides an overview of the main features and

 functions of the EZT-560i controller.

                          Honeywell HMC5843 Video Podcast

           The Video Link Provides an overview of the main features and

                      functions of the HMC5843!

Featured Products

Anritsu MA24126A

A microwave USB power sensor that can make highly-accurate power measurements from 10MHz to 26GHz over 60dB of dynamic range



FREE Circuit-Board Debug Tool

Debugging boards too crowded for traditional probing just got a whole lot easier. Best of all, you can get started absolutely free of charge with JTAG Live's Buzz module.



Anritsu MS4640A VectorStar VNA

Introducing Anritsu's MS4640A Series VectorStar™ VNA, a uniquely broadband, 70 kHz to 70 GHz vector network analyzer with the best accuracy and measurement speed for the toughest microwave applications.



Yokogawa DLM 2000

DLM 2000, Mid-range laboratory oscilloscope with mixed signal models and bandwidths from 200 to 500MHz, two and four channel models, and memory from 1 to 125 megapoints.



Modular system includes generator, coupling, calibration, and waveform verification solutions f to meet the requirements of CS106, CS115, & CS116, DO 160 Sections 17 & 19, Airbus AMD 24C, & more.



RS105

Turnkey solutions. Wide range of antenna sizes and pulse generators to produce specified 50 kV/m. Sets up in under 4 hours. Excellent field uniformity, reliability & reproducibility.



EADS (Tabor) Pulse Master Series

The Pulse Master Series is a series of Pulse Generators that generate a complete array of standard, arbitrary, sequenced and modulated wave forms.





TDI-Dynaload XBL Series Electronic Loads

The XBL series provides power form 800-6000 watts, voltages from 50-1000 volts. Air cooled, liquid cooling & resistive models. Constant Current, Constant Resistance, Constant Power, & Constant Voltage Operation
